Racing Coilover Shock Struts compatible for Holden VE Commodore Sedan Wagon Ute Adj. Height

SKU

3002034346

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

1. Adjustable Height

Able to lower ride height by 1''-3''; allows user to have a more aggressive stance and can adjust without taking coilovers out the car

2.High Quality Components

Most components of the suspension parts are made from 6061-T6 aluminum to increase strength and rigidity

3.High Tensile Strength Spring

Tested under a 600,000 time continuous compression test, the spring distortion was less than 0.04%

4.Twin-tube Construction

Twin-Tube shock design is used for low internal frictional resistance and dust boot protects damper seal

Application

Compatible for Holden Commodore VE Sedan 2006-2013\
compatible for Holden Commodore VE Wagon 2008-2013\
compatible for Holden Commodore VE Ute 2007-2013

Specification

Top mounts: Front and rear OE top mounts required \
Damping: not available\
Shock type: Twin tube\
Adjustable camber plate: No\
Spring preload: 7-10 mm\
Spring rate Front: 7 kg/mm (392 lbs/in)\
Spring rate Rear: 11 kg/mm (616 lbs/in)\
Spring length Front: 200mm\
Spring length Rear: 185mm\
Adjustable height: lowering 1-3 inch\
Coilover overall length Front: 430mm-510mm\
Coilover overall length Rear: 405mm-445mm\
Color: golden

Package included

product included: springs and shocks for front and rear, no top mounts included

Dimension

Size: 63*51*21 cm\
Weight: 24.5 kg

Feature

1. Lowered height adjustment from 1" - 3" which allow lower center of gravity and also add a more aggressive stance \
2. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent\
3. Adjustable Camber Plate and Pillow ball top mount for sharpening steering response.( for some models)\
4. CNC machined Aluminum top mounts and lockers-- - excellent strength, and save weight\
5. Heavy Duty Steel Lower Mounts--- Highly Durable & Reliable\
6. High tensile spring--- 600,000 times continuously test to assure it's high tensile strength.\
7. All inserts come with fitted long rubber boots--- To protect the damper more well and be durable.\
8. Twin-Tube structure ---provides excellent handling & control characteristics for most driving conditions\
9. Corrosion Finish - Anodized Aluminum And Powder Coated Carbon Steel Parts
